View In:   ArcGIS Online Map Viewer

Name: Sidewalks

Display Field: TYPE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Sidewalk centerlines contain the centerline of sidewalks and crosswalks. The original data capture of the data in this layer was completed in 2014 using stereo models from the 2009 Virginia State imagery. Subsequent to that an update capture was completed in 2022 using stereo models from the 2017 Virginia State imagery. The most recent planimetric update was completed in 2024 using orthoimagery from the 2023 and 2022 Eagleview Orthophotos.The centerlines of sidewalks along major and minor transportation features are captured as well as centerlines of connectors which are typically crosswalks or connections across driveways or parking lot entrances. Centerlines were captured rather than edges in order to be able to use the sidewalks as part of a network system. The sidewalks are attributed with a width value if it is necessary to buffer the centerlines to get an approximate area that is covered by the sidewalk for impervious surface calculations.Contact: Fairfax County GIS DivisionData Accessibility: Publicly AvailableUpdate frequency: As NeededLast Revision Date: 3/1/2024Creation date: 1/1/2013Feature Dataset Name: GISMGR.PLANIMETRICLayer Name: GISMGR.SIDEWALKS_CENTERLINE

Copyright Text: Fairfax County, Virginia;Fairfax County Department of Information Technology GIS Division, Avineon Inc. and Timmons Group (2017 & 2023 Updates), Geodecisions and Plangraphics, Inc (2009 Updates)

Default Visibility: true

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 10000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 1.1757500755250007E7
YMin: 6917531.158250004
XMax: 1.1898796087249994E7
YMax: 7067615.216250002
Spatial Reference: 102746  (2283)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: CONNECTOR
  Label: Connector
  Description: N/A
  Symbol:
  Style: esriSLSDashDot
  Color: [78, 78, 78, 255]
  Width: 1
• Value: SIDEWALK
  Label: Sidewalk
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 115, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: TYPE

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• TYPE ( type: esriFieldTypeString, alias: Type, editable: true, nullable: true, length: 15, defaultValue: null, modelName: TYPE , Coded Values: [SIDEWALK: Sidewalk] , [CONNECTOR: Connector] )
• WIDTH ( type: esriFieldTypeSmallInteger, alias: Width, editable: true, nullable: true, defaultValue: null, modelName: WIDTH , Coded Values: [2: Less than 2 feet] , [4: 2-4 feet] , [6: 4-6 feet] , ...2 more... )
• SOURCE ( type: esriFieldTypeString, alias: Source, editable: true, nullable: true, length: 20, defaultValue: null, modelName: SOURCE , Coded Values: [ORTHO1997: 1997 Orthophotography] , [ORTHO2002: 2002 Orthophotography] , [SITEPLAN: Site Plan] , ...15 more... )
• SURFACE_TYPE ( type: esriFieldTypeString, alias: Surface Type, editable: true, nullable: true, length: 20, defaultValue: null, modelName: SURFACE_TYPE , Coded Values: [CONCRETE: Concrete] , [ASPHALT: Asphalt] , [BRICK: Brick] , ...1 more... )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• created_user ( type: esriFieldTypeString, alias: created_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: created_user )
• created_date ( type: esriFieldTypeDate, alias: created_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: created_date )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: last_edited_user )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: last_edited_date )
• Shape__Length ( type: esriFieldTypeDouble, alias: SHAPE.STLength(), editable: false, nullable: false, defaultValue: null, modelName: SHAPE.STLength() )

Types:

ID: CONNECTOR
Name: Connector
Domains:
• TYPE:
  Inherited
• WIDTH:
  Inherited
• SOURCE:
  Inherited
• SURFACE_TYPE:
  Inherited
Templates:
• Name: CONNECTOR
  Description:
  Prototype:
  SOURCE: null
  SURFACE_TYPE: null
  TYPE: CONNECTOR
  WIDTH: null

  Drawing Tool: esriFeatureEditToolLine

---

ID: SIDEWALK
Name: Sidewalk
Domains:
• TYPE:
  Inherited
• WIDTH:
  Inherited
• SOURCE:
  Inherited
• SURFACE_TYPE:
  Inherited
Templates:
• Name: SIDEWALK
  Description:
  Prototype:
  SOURCE: null
  SURFACE_TYPE: null
  TYPE: SIDEWALK
  WIDTH: null

  Drawing Tool: esriFeatureEditToolLine

---

Capabilities: Query

Sync Can Return Changes: true

Is Data Versioned: true

Supports Rollback On Failure: false

Supports ApplyEdits With Global Ids: false

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
