Name: 1ft Elevation Contours - NAVD88

Display Field: CONTOUR

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Product: Contour data for Fairfax County, Virginia as part of the required deliverables for the 2022 VA NorthernVA 1 B22 project administered by the U.S. Geological Survey.</SPAN></P><P><SPAN /></P><P><SPAN>Project description: Class 2 (Ground) lidar points in conjunction with the hydro breaklines were used to create a 1-foot hydro-flattened Raster DEM. Geographic Extent: Alexandria, Arlington, Fairfax, Falls Church, Loudoun, Manassas, Manassas Park, and Prince William counties Virginia, covering approximately 1351 square miles. Dataset Description: The lidar project called for the Planning, Acquisition, processing and derivative products of lidar data to be collected at a nominal pulse spacing (NPS) of 0.35 meters. Project specifications are based on the U.S. Geological Survey National Geospatial Program Base Lidar Specification 2022, Revision A. The data was developed based on a horizontal projection/datum of NAD83(2011), State Plane Virginia North, Feet and vertical datum of NAVD88 (GEOID18), Feet. Lidar data was delivered as processed Classified LAS 1.4 files, formatted to 4404 individual 3000 ft x 3000 ft tiles clipped to the DPA, as tiled intensity images, as tiled bare-earth DEMs, as tiled all-return MSHRs; all tiled to the same 3000 ft x 3000 ft schema. Ground Conditions: Lidar was collected in late 2022, while no snow was on the ground and rivers were at or below normal levels. In order to post process the lidar data to meet task order specifications and meet ASPRS vertical accuracy guidelines, Sanborn Map Company, Inc., established a total of 16 ground control points that were used to calibrate the lidar to known ground locations established throughout the project area. An additional 84 independent accuracy check points, 47 in Bare Earth and Urban landcovers (47 NVA points), 37 in Tall Grass and Brushland/Low Trees categories (37 VVA points), were used to assess the vertical accuracy of the data. These check points were not used to calibrate or post process the data.</SPAN></P><P><SPAN>Contact: </SPAN><SPAN STYLE="font-size:14pt"><SPAN>Fairfax County Department of Information Technology GIS Division</SPAN></SPAN></P><P><SPAN>Data Accessibility: Publicly Available</SPAN></P><P><SPAN>Update frequency: Never</SPAN></P><P><SPAN>Last Revision Date: 1/28/2025</SPAN></P><P><SPAN>Creation Date: 1/28/2025</SPAN></P><P><SPAN>Feature Dataset Name: DIT_GIS.GISMGR.TOPOGRAPHIC</SPAN></P><P><SPAN>Layer Name: GISMGR.CONTOURS_1FT_NAVD88</SPAN></P></DIV></DIV></DIV>

Copyright Text: Fairfax County, Virginia; Fairfax County Department of Information Technology GIS Division; U.S. Geological Survey, Sanborn Map Company, Inc.

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 20000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.1741442044750005E7
YMin: 6899929.462500006
XMax: 1.1901267376249999E7
YMax: 7072378.604499996
Spatial Reference: 102746  (2283)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Index
  Label: Index
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 1
• Value: Intermediate
  Label: Intermediate
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: [CONTOUR]
Use Coded Values: true
Symbol:
Color: [230, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Arial
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: NaN
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CONTOUR ( type: esriFieldTypeDouble, alias: Elevation in Feet )
• TYPE ( type: esriFieldTypeString, alias: Contour Type, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: SHAPE )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
