Parent Layer: Inadequate Outfalls

Name: Inadequate Outfall Pour Points

Display Field: INADEQUATE_OUTFALL_ID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN><SPAN>This dataset is a selection of known erosion and flooding problems throughout the County. The data is intended primarily to assist site plan preparers with establishing the existence of known erosion and flooding problems. </SPAN></SPAN></P><P><SPAN>Increased volumes of sheet flow that will cause or contribute to erosion, sedimentation, or flooding of down gradient properties or resources shall be diverted to a stormwater management facility or a stormwater conveyance system that conveys the runoff without causing down-gradient erosion, sedimentation, or flooding per stormwater Management Ordinance 124-4-4.E. Minimum Standard (MS) 19 of the Virginia Erosion and Sediment Control Regulations (9VAC25-840-40.19) requires stormwater discharge from permitted projects be diverted to an adequate conveyance or detention facility.</SPAN></P><P><SPAN><SPAN>This data documents known inadequacies in the stormwater conveyance system. Plan preparers should and County staff will use this information when evaluating compliance with requirements to discharge storm water to an adequate system or detention facility.</SPAN></SPAN></P><P><SPAN><SPAN>The erosion and flooding problems identified in the layer were determined using the following county datasets: </SPAN></SPAN></P><UL><LI><P><SPAN>Stream Physical Assessment 1.0 Erosion </SPAN></P></LI><LI><P><SPAN>Stream Physical Assessment 1.0 Reach Habitat</SPAN></P></LI><LI><P><SPAN>Stream Physical Assessment 1.0 Head Cuts </SPAN></P></LI><LI><P><SPAN>Stream Physical Assessment 2.0 </SPAN></P></LI><LI><P><SPAN>Open Channel Inspections</SPAN></P></LI><LI><P><SPAN>Stormwater Planning Division Investigation </SPAN></P></LI></UL><P><SPAN><SPAN>Contact: Land Development Services</SPAN></SPAN></P><P><SPAN><SPAN>Data Accessibility: Publicly Available</SPAN></SPAN></P><P><SPAN><SPAN>Update Frequency: As Needed</SPAN></SPAN></P><P><SPAN><SPAN>Last Revision Date: </SPAN></SPAN><SPAN><SPAN>1/11/2021</SPAN></SPAN></P><P><SPAN><SPAN>Creation Date: </SPAN></SPAN><SPAN><SPAN>1/11/2021</SPAN></SPAN></P><P><SPAN><SPAN>Layer Name: LDSAMGR.INADEQUATE_OUTFALL_POUR_POINTS</SPAN></SPAN></P><P><SPAN /></P></DIV></DIV></DIV>

Copyright Text: Fairfax County, Virginia; Land Development Services

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 75000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8628127.58099142
YMin: 4673362.466783607
XMax: -8575737.256248226
YMax: 4728381.670133056
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [85, 255, 0, 255]
Size: 6.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• INADEQUATE_OUTFALL_ID ( type: esriFieldTypeString, alias: Inadequate Outfall ID:, length: 5 )
• DATA_SOURCE ( type: esriFieldTypeString, alias: Data Source:, length: 50 , Coded Values: [Open Channel Inspections: Open Channel Inspections] , [Stream Physical Assessment 1.0 Reach Habitat: Stream Physical Assessment 1.0 Reach Habitat] , [Stream Physical Assessment 1.0 Erosion: Stream Physical Assessment 1.0 Erosion] , ...4 more... )
• DRAINAGE_AREA ( type: esriFieldTypeDouble, alias: Drainage Area: )
• DETERMINATION ( type: esriFieldTypeString, alias: Determination:, length: 30 , Coded Values: [Erosion: Erosion] , [Vertical Erosion: Vertical Erosion] , [Flooding: Flooding] , ...3 more... )
• WATERSHED ( type: esriFieldTypeString, alias: Watershed:, length: 20 , Coded Values: [Accotink Creek: Accotink Creek] , [Belle Haven: Belle Haven] , [Bull Neck Run: Bull Neck Run] , ...27 more... )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
