Stream Monitoring Handbook

This handbook is designed to be an overview of stream monitoring information. It is NOT designed as a replacement for field training sessions. If you would like additional training or have any suggestions about other materials that would be helpful, please contact the coordinator.

It is easy to forget some details when monitoring quarterly. Although you are a certified monitor, you may want some review of the details of sampling and identification. You are encouraged to join other monitors or invite other monitors to join you. If you ever have any questions, please do not hesitate to contact the coordinator.

This handbook is broken into four sections: safety, equipment, biological monitoring information, and common benthic macroinvertebrates.




Before Monitoring:

  • If you would like some additional helpers, please contact the coordinator.
  • Make sure that someone knows the date, time, and location that you will be monitoring so that if you are injured, someone will know that you are missing or late in returning.
  • Find out the phone number of the nearest medical center to your monitoring site and make sure you have cell phone coverage at your monitoring site. You may have to climb to the top of the ridge to get reception.

Rules to Monitor by:

  • Never monitor when the water is at flood stage or is flowing much swifter than normal. It is better to delay your monitoring event than to risk drowning or broken bones. A good rule of thumb is not to monitor if the water is above your knee.
  • During monitoring, keep your hands away from eyes and mouth. ALWAYS WASH YOUR HANDS THOUROUGHLY WITH SOAP AND WATER AFTER MONITORING. NEVER EAT WITHOUT WASHING YOUR HANDS FIRST. Many of our streams have elevated e. coli levels. Do not monitor your stream with open cuts.
  • If the water appears to be polluted (strong smell of sewage or chemicals, unusual colors, dead fish) please postpone your monitoring.

To protect yourself, it is advised that you:

  • Wear rubber boots or waders to keep your legs and feet dry and to minimize contact with water. Rubber boots will also offer protection from ticks. It is better to wear old sneakers than sandals because they offer protection from glass and sharp rocks in the stream.
  • Wear rubber gloves to reduce contact with water and to protect cuts from trash in the stream.


Snakes are of concern when monitoring in an aquatic environment, especially slow moving water with overhanging vegetation. Most snakes in aquatic environments are not venomous. If you approach your site through thick high grass, thump the ground in front of you with a walking stick. Snakes will feel the vibrations and will move away. Snakes are deaf so loud noises will not scare them away. The only venomous snake in Fairfax County is the Copperhead.

In case of snake bite:

  • Remain calm. Take a few deep breaths and keep movement to a minimum.
  • Remove all jewelry and watches if bitten on the hand or arm. Snake venom may cause the area to swell.
  • Have your monitoring partner call 911 for help if you suspect a venomous bite.


  • If you do find a tick on your skin, remove it right away. To remove an attached tick, use tweezers to grasp the tick at the skin surface.





Monitoring Kit Includes:

  • Net
  • Magnifier boxes
  • Ice-cube trays
  • Forceps
  • Paint brushes
  • Laminated bug identification cards
  • Waders or Rubber boots

Additional Equipment that you may want to check out, add to your kit or purchase:

  • Table
  • Chairs
  • Magiscope (field microscope)
  • Additional Magnifiers

Taking Care of Monitoring Equipment

PLEASE TAKE THE TIME TO CLEAN THE MONITORING EQUIPMENT! Please rinse out all equipment. Please return the kit looking better than when you checked it out.

Taking care of the net:

In the field, be careful to not drag the net through areas with sharp vegetation. It is very easy to tear the nets accidentally. They should be carefully carried to the monitoring location. If your site is located so that you have to walk through thick vegetation, it is recommended to carry the net in a plastic bag.

After monitoring, wash the net in the stream to remove any algae or macroinvertabrates. Carefully inspect the net to make sure all the macroinvertebrates are set free.

Once home, please hose down the net. PLEASE SET UP THE NET TO DRY - they develop a unique smell if they dry in car trunks and other such places.

If there are any tears in the net, please report this to the coordinator.

Gilled Snail

Gilled Snail

Biological Monitoring Information

Biological Monitoring Directions

Sampling of benthic invertebrates should be done according to the Virginia Save Our Streams (VASOS) Modified Method for rocky bottom streams. Instructions can be found on the VASOS website:






Common Benthic Macroinvertebrates:

Below are illustrations and pictures of common benthic macroinvertebrates. As you can see, some macroinvertebrates can be easily confused because they look very similar! Be sure to take care in identifying your macroinvertebrates so that you do not confuse any of them.

Descriptions have been provided under each picture to help distinguish the benthic macroinvertebrates from each other. The Virginia Save Our Streams website also has very useful training resources to assist you in identifying common invertebrate species. These resources can be found on their Training Resources ( and Stream Insect and Crustacean ID webpages (

Three Tails
Gills on sides of abdomen
One set of wing pads
Legs stretched to the sides
Six legs
Two Tails
No gills on abdomen
Two sets of wing pads
Legs stretched to the sides
Six legs
Two brushy tails, with hooks (usually)
If have gills, gills are underneath abdomen
No wing pads
Legs held in front of body
Six legs
Other notes: Lots of variation. Some will be in cases, some will be fat and fleshy, some thin. Most common one is pictured above. It is a free-living caddisfly (no case) and will have three hardened plates.
Midge Fly
Midge fly
No gills
No wing pads
Proleg held under body
One proleg
Long, thin body - does not thicken at end
Head clearly visible - no projections from head
Tend to "convulse" when moving
Black fly
Black Fly
No tails - have a suction pad instead
No gills
No wing pads
Proleg held under body
One proleg
Body thickens into a rounded abdomen
Head has mouth brush
Tend to attach to surface
Crane fly
Crane Fly
No tails - fingerlike projections instead
No gills
No wing pads
No legs
Thick, caterpillar-like body
Body often semi-transparent
Beetle Larvae
Beetle Larvae
No tails - but gills often pulse in and out
Gills are sometimes found on end
No wing pads
Legs held in front of body usually

This project was initiated by the Northern Virginia Soil and Water Conservation District (NVSWCD).

This information was designed for students, citizen volunteers, and others interested in benthic macroinvertebrates and/or biomonitoring to provide assistance in identification of specimens and to provide information on the habitat and general ecology of common benthic macroinvertebrates.

All drawn images are from Aquatic Entomology: the Fishermen's and Ecologist’s Illustrated Guide to Insects and Their Relatives (McCafferty 1981).

The picture of the stonefly is from the Pekin High School River Watch program.
