Project News
The Jones Branch Connector is complete. It is an important milestone in reaching the goals of Fairfax County in its redevelopment of the Tysons area. These goals include the development of a grid of streets that are pedestrian friendly, support multi-modal forms of transportation such as bicycles and buses and contribute to a more urban, “downtown” feel than currently exists. The Jones Branch Connector provides an alternative route between Tysons East (Route 123) and West (Jones Branch Drive), bypassing the I-495/Route 123 Interchange. The connection improves the operations along the adjacent road systems. This connection extends and widens existing lanes eastward along Scotts Crossing Road, ending at Route 123 adjacent to the McLean Metro Station. The project includes Federal, State, and local (Fairfax County) funding.
Additional photos of the completed project:
- Jones Branch Connector (JBC) and Jones Branch Drive Intersection
- Westbound view of JBC and Jones Branch Drive
- Eastbound view of JBC at Bridge
- Eastbound view
- Westbound view
- Eastbound view at Rt. 123
Project Limits
From: Jones Branch Drive (Route 5062) To: Dolley Madison Boulevard (Route 123)
Project Status
(Updated 3/8/19): The project is under construction, and one lane is upon to traffic in each direction from Route 123 to Jones Branch Drive. Final construction completion is scheduled for Fall 2019. The following information is available:
- A Project Overview showing engineering design:
- An Aerial Overview showing the project and adjacent property features
- Renderings of the proposed bridge over I-495:
- Typical Sections of the Jones Branch Connector Bridge and Roadway that include two travel lanes on each side of the median (for a total of four lanes), turn lanes, bike lanes, and a streetscape area available for sidewalks, benches, and plantings behind the curb :
- Typical Section 1
- Typical Section 2 - Roadway
- Typical Section 3 - Bridge
- The Public Hearing Plans
